Photo Galleries
Boilers & Hot Water
6,000,000 BTU high efficiency hot water plant
500 GPM direct injection steam to hot water generators.
Two 150 HP high-pressure high-efficiency on-demand steam boilers with built-in economizers.
High and low pressure duplex VFD hot water pumping system with 3,000 gallon storage tank.
100 HP, 15 PSI, High-Efficiency Cast Iron Steam Boiler for Process and Heating
Hot water system stores 3,500 gallons of 180° F water produced at over 92% efficiency. Mixing valves, VSD pumps and bladder tank are used to deliver water to 3 different locations at 3 different temperatures with a constant pressure of 60 PSI. Total flow varies from 10 to 300 GPM.
12 on demand water heaters totaling 2,400,000 BTU/HR heat 50 GPM of water from 55° to 140° F at 95% efficiency
3,500 gallon hot water heat recovery and storage with supplemental 50 GPM on demand hot water system.
Triplex 1,000,000 BTU Boilers: The system heats a water source heat pump loop serving an industrial mill complex.
Chiller Systems
Variable Speed Drive Conversion of 500 Ton Ammonia Chiller
8,000 Sq Ft Mechanical Room Restoration. Before and after views, with 600-ton VSD centrifugal chiller plant
600-Ton Centrifugal Chiller Plant
350-Ton Chiller System. System utilizes closed evaporative glycol condensor cooling
300-Ton Air-Cooled Central Chiller with Sound Attenuation
125-Ton Chiller with 900 GPM Pumping Station
100-Ton Low Temperature Chiller. Chiller pumping skid with air compressor cooling and heat recovery skid
Cooling Tower Systems
16,000,000 BTU Cooling Tower. Three cell sound-attenuated 16,000,000 BTU cooling tower with automatic flow control valving
1,700,000 BTU Closed Evaporative Cooling Tower. Submersed sump pump directs sump drainage back to the facility.
2,000,000 BTU Explosion-Proof Cooling Tower Installed on a Structural Steel Frame
Closed Evaporative Cooling Tower. Four-cell closed evaporative glycol cooling tower
350 Ton Closed Evaporative Cooling Tower. One of two 350 ton closed evaporative cooling towers serving chiller plant and offering water side economizer free cooling
500 Ton Dual Cell Open Evaporative Cooling Tower
Free Cooling
Closed Evaporative Free Cooling with Automatic Activation
Radiator Free Cooling with Automatic Activation
Combination Chiller and Automatic Free Cooling Radiator in One Package
Closed Evaporative Free Cooling with Outdoor Weather-Protected Pumping Station and Control System
Heat Recovery
Heat recovery from three 125 HP oil free air compressors and heat of compression air dryers, used for preheating boiler feed water and CIP process.
1.3 million BTU air compressor waste heat make-up air unit recovery system
Outlet 40,000 CFM 4,000,000 BTU/HR radiator heat recovery system
125 HP VSD air compressor custom modified to co-generate 173° hot water
Combination 335 HP air compressor cooling and 750,000 BTU heat recovery skid serving beverage bottle warming process
Heat Recovery Skid. High-temperature boiler feed water heat recovery interface
Hydraulic Room with Heat Recovery. Waste hydraulic and chiller heat provides 100% building heating through water source heat pumps.
Rooftop Heat Recovery. Custom built 10,000 CFM heat exchangers reclaim 80% of exhaust heat and preheat inlet air.
Air Compressor Heat Recovery; Preheats Boiler Make Up
Heat Exchanger Pump Skid. Waste compressor energy is used to heat boiler feed, steam generator supply, and building HVAC.
Air Compressor Heat Recovery. Provides 180F supply to steam generator through a customized constant flow level control system.
2,750,000 BTU/HR heat recovery from a 30,000 CFM regenerative thermal oxidizer produces 31 gallons a minute of 200° F hot water.
Waste heat from 500 HP air compressor pre-heating well water that serves process needs.
HVAC
Complete factory rooftop unit conversion from steam heat to gas heat.
6 Million MBH Central Boiler Plant
Open Concept Air Handling Units
Indoor Air Handlers with Heating and Cooling Coils
Direct and Retrofit Rooftop Replacements
Complete Rooftop Replacement Services
Helicopter Rigging
HVAC Design and Install for Historic Mill. BEFORE & AFTER VIEWS of 50,000 square foot system for historic mill restoration project.
45 Ton DDC-Controlled Heating/Cooling System. Turn-key system serving 30,000 square foot retail space.
IMEC Services
Full Construction Services and Project Management of All Building Trades
Adaptive Re-Use of Existing Structures
Comprehensive Testing. Every system is comprehensively tested before shipment to ensure peak performance and reliability.
Complete Plant Utility and HVAC Installation
Full Mechanical, Piping, and Insulation
Cooling Tower Rigging and Installations
Commissioning and Final Testing by Skilled In-House Technicians
Custom Package Fabrication. The cleanliness and efficiency of our fabrication facility reflects the workmanship and value crafted into every system.
In-House Design & Build. All systems are designed and built in-house at the IMEC/Systems H2O manufacturing plant, guaranteeing exceptional quality.
Variable Speed Drive Chiller Conversions
Validated Commissioning at Regulated Facilities
Process Controls
Ammonia Plant Customized Control and Energy Management System
Heat exchangers and flow control valves heat or cool the process to maintain precise product temperature of +/-1° F.
Chilled Water Distribution Manifold. Chilled water distribution manifold surveys individual precise temperatures to nine different lab devices.
Customized Cooling System Controls
Production-Line Temperature, Pressure, and Level Control
Process Heat Exchangers
1,500,000 BTU-Per-hHour Plate Heat Exchanger
Sanitary 30 GPM soy milk pumping and temperature control system
Free Cooling Duplex Oil Cooling Skid (save $42,000 per year!)
300 PSI Heat Exchanger. 300 PSI steam heating loop with steam temperature control and condensate return.
Biomedical Stainless Steel Heat Exchanger Pump Skid
Simplex Heat Exchanger with Duplex Pumps
Duplex Heat Exchanger with Duplex Pumps
Pumping Stations
2,000 gallon hot water insulated stainless steel tank with 200 GPM VFD duplex pumps with 110 gallon pressure-buffer tank and Allen Bradley control system.
1,000 GPM Chiller/Pump Station. Designed with remote control system.
1,000 GPM Pump Skid. 1000 GPM cooling and chilling pump stations featuring automatic controls and redundant pumps.
Glycol Duplex Pumping Station. Features built-in remote freshwater spray system.
Duplex Pumping Stations. 50 GPM and 1600 GPM pumping stations for closed evaporative systems.
Triplex Pumping Skid with Three Pumps. Features a microprocessor control and automatic rotation of three 50% capacity pumps.
Duplex Pumping Station. Skid features a DirectReturn control valve and sidestream filtration with automatic backwash.
Biomedical Heat Exchanger Pump Skid. Built with stainless steel.
Variable Speed Drive Pump Skid. Dual temperature speed drive system, with adjustable temperature control and 3-way modulating mixing valve.
Explosion-Proof 800 Gallon Per Minute Cooling Tower Pumping Station. Includes sidestream filtration.
Stainless Steel Heating and Pumping Skid with 1,000,000 BTU Boiler
Duplex 1500 GPM Pumping Station for Dual Cell Open Evaporative Cooling Tower
Sanitary 30 GPM soy milk pumping and temperature control system
Other Systems
Rooftop Radiator with Trouble-Free Closed Loop Cooling. Features shell and tube trim cooler
Radiator Duplex Glycol Pumping Station
Compressor
Vacuum Pump
Vacuum Skid System
